Supports AMD Ryzen CPU / APU
AMD B450 single chip architecture
Supports 2-DIMM DDR4-3200+(OC)/ 2933/2667/2400/2133/1866 up to 64G
maximum capacity
Supports HDMI
Supports USB 3.2 Gen1

Chipset AMD B450
CPU SUPPORT Socket AM4 supports AMD A-series APU, Ryzen APU / Ryzen
CPU
* Please refer to www.biostar.com.tw for CPU support list.
MEMORY Supports Dual Channel DDR4 1866/2133/2400/2666/2933/3200+(OC)
2 x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory
Each DIMM supports non-ECC 8/16/32 GB DDR4 module
* Please refer to www.biostar.com.tw for Memory support list.
INTEGRATED VIDEO By CPU model
Supports DX12
Supports HDCP
STORAGE 4 x SATA III Connector (6Gb/s) : Supports AHCI e RAID 0, 1,
10
LAN Realtek RTL8111H-VB
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
AUDIO CODEC ALC897
7.1 Channels, High Definition Audio
USB 4 x USB 3.2 (Gen1) port (2 on rear I/Os and 2 via internal
headers)
8 x USB 2.0 port (4 on rear I/Os and 4 via internal headers)
EXPANSION SLOT 2 x PCIe 2.0 x1 Slot
1 x PCIe 3.0 x16 Slot (The bandwidth is depended on CPU)
REAR I/O 1 x PS/2 Keyboard/ Mouse
1 x VGA Port
1 x HDMI Port
1 x LAN port
2 x USB 3.2 (Gen1) Ports
4 x USB 2.0 Ports
3 x Audio Jack
INTERNAL I/O 4 x SATA III 6.0Gb/s Connectors
2 x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
1 x 4-Pin Power Connector
1 x 24-Pin Power Connector
1 x CPU Fan Connector
1 x System Fan Connector
1 x Front Panel Header
1 x Front Audio Header
1 x Clear CMOS Header
1 x COM Serial Header
H/W MONITORING CPU / System Temperature Monitoring
CPU / System Fan Monitoring
Smart / Manual CPU Fan Control
System Voltage Monitoring
